Panasonic GX80 PDF User Manual
Did you lose or misplace the instruction manual that came with your Panasonic Lumix DMC-GX80? It happens all too easily, but fortunately Panasonic makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the GX80 offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.
That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.
Also, you might want to check out the video tutorial on the Panasonic Lumix DMC-GX80 below.
In any case, the GX80 (called Panasonic GX85 in some regions) is an advanced imaging tool, whose many features merit serious attention. This mirrorless interchangeable lens camera was announced on April 5th, 2016, which means that, as of today, the camera is 3094 days old (young?). Given that the GX80 is a relatively recent model, it forms part of the current Panasonic product line-up.
Panasonic's advanced owner manual for the GX80
The camera's advanced owner manual is 338 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the GX80 is included towards the bottom of this webpage.
Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!
Click on the button below to download the pdf version of the Panasonic Lumix DMC-GX80 manual to your computer. The file will open in a new browser window.
If you prefer to read the user guide in another language, please check the respective availability on Panasonic's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.
Printed, hardcopy versions of the Panasonic GX80 manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.
Video tutorial for the Panasonic Lumix DMC-GX80
Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your GX80 by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.
Once again, the Panasonic GX80 is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.
Panasonic GX80 FAQ
Below are some additional questions and answers concerning some particular features of the GX80.
What technology is the imaging sensor in the Panasonic GX80 based on?
The camera is build around a CMOS (Complementary Metal–Oxide–Semiconductor) sensor.
Which image processing chip is used in the Panasonic GX80 to convert the raw signal into an image file and perform noise reduction and image sharpening?
Panasonic equipped the GX80 with the Venus image processor.
What is the ISO sensitivity range of the Panasonic GX80?
The camera has a native sensitivity range from ISO 200 to ISO 25600, which can be extended to ISO 100-25600.
What is the life expectancy of the shutter in the Panasonic Lumix DMC-GX80?
Panasonic does not publish a shutter rating for the GX80. Yet, shutters in comparable cameras from other manufacturers are said to be good for at least 100 000 actuations. It should be noted, though, that this number represents a Mean Time before Failure. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust an expected shutter life of 100 000 shots over, say, three years, one would have to take about 100 pictures each and every day.
How do I find the shutter count on my Panasonic GX80?
Panasonic embeds the number of shutter actuations in hidden menus. You can check the number of shots that your GX80 has taken up to now by carefully following the steps described on the Panasonic GX80 shutter count page.
Is completely silent shooting possible with the Panasonic GX80?
The camera has an electronic shutter option, so that it is indeed feasible to capture images without any shutter noise.
Do I need to purchase an external camera trigger to shoot time-lapse sequences with the Panasonic GX80?
No, the Panasonic Lumix DMC-GX80 has an intervalometer built-in, so that low frequency shooting (for example, flower blooming, sunset, moon rise) can be undertaken without the need to purchase a separate external intervalometer and related software.
Is it difficult to use manual focus lenses with the Panasonic GX80?
The GX80 offers focus peaking as a manual focus aid. This feature works by placing a colored highlight on in-focus zones within the image.
Does the Panasonic GX80 feature an autofocus assist light?
Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.
What is the fastest shutter speed that can be used with the Panasonic GX80 for flash photography?
The GX80's flash sync speed is 1/160 sec.
Does the Panasonic GX80 support the Ultra High Speed (UHS) bus interface for SD cards?
Yes, the camera can indeed use UHS-I cards (data transfer speed of up to 104 MB/s).
Which battery does the Panasonic GX80 use?
The camera gets its power from the Panasonic DMW-BLG10 (here at amazon), which is a rechargeable Lithium-Ion power pack.
Where can I find the best deals for the Panasonic GX80?
Grey imports from Asia, as found on ebay, are often very attractively priced. However, these cameras come without a warranty from Panasonic.
Further reading
How does the GX80 stack up against available alternatives? If you would like to see a side-by-side review with another camera, just use the search menu below. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.
- Canon 4000D vs Sony A9 II
- Canon 5DS vs Panasonic GX80
- Canon 70D vs Panasonic GX80
- Fujifilm GFX 50R vs Panasonic GX80
- Fujifilm X-T4 vs Sony A9 II
- Nikon L840 vs Panasonic GX80
- Nikon Z7 vs Sony A9 II
- Nikon Zf vs Sony A9 II
- Panasonic GX80 vs Panasonic GX800
- Panasonic GX80 vs Sony A68
- Sony A9 II vs Sony A99 II
- Sony A9 II vs Sony RX0
Core camera specifications
Here is a list of the main features and technical characteristics of the Panasonic Lumix DMC-GX80.
Camera Model | Panasonic GX80 | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Micro Four Thirds lenses | |
Launch Date | April 2016 | |
Launch Price | USD 799 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | Four Thirds Sensor | |
Sensor Size | 17.3 x 13.0 mm | |
Sensor Area | 225 mm2 | |
Sensor Diagonal | 21.6 mm | |
Crop Factor | 2.0x | |
Sensor Resolution | 15.8 Megapixels | |
Image Resolution | 4 592 x 3 448 pixels | |
Pixel Pitch | 3.77 μm | |
Pixel Density | 7.04 MP/cm2 | |
Moiré control | no AA filter | |
Movie Capability | 4K/30p Video | |
ISO Setting | 200 - 25 600 ISO | |
ISO Boost | 100 - 25 600 ISO | |
Image Processor | Venus | |
DXO Sensor Quality (score) | 71 | |
DXO Color Depth (bits) | 22.9 | |
DXO Dynamic Range (EV) | 12.6 | |
DXO Low Light (ISO) | 662 | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.70x | |
Viewfinder Resolution | 2765k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1040k dots | |
LCD Attachment | Tilting screen | |
V-logging Friendliness | No front-flip | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 8 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | Electronic Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Image Stabilization | In-body stabilization | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Wifi Support | Wifi built-in | |
Body Specs | ||
Battery Type | Panasonic DMW-BLG10 power pack | |
Battery Life (CIPA) | 290 shots per charge | |
In-Camera Charging | USB charging | |
Body Dimensions |
122 x 71 x 44 mm (4.8 x 2.8 x 1.7 in) |
|
Camera Weight | 426 g (15.0 oz) |
