How many Megapixels does the Panasonic GX800 have?

The Panasonic Lumix DMC-GX800 is equipped with a a Four Thirds sensor that offers an image resolution of 15.8 megapixels (MP), or 15.8 million pixels. With its native aspect ratio of 4:3, the sensor has 4 592 horizontal pixels and 3 448 vertical pixels.

A 35mm film slide or negative contains 5-15 MP of useful detail, so that the Panasonic GX800 can be considered to be a high-resolution camera that outresolves any 35mm film camera.

camera

A high megapixel count makes it possible to crop any captured image substantially or to make very large prints from the image file. On the downside, large megapixel files are slower to transfer and take up more storage space on the computer harddisk. Also, high-resolution imaging requires sharper, more expensive lenses than low-res picture taking.

How large can I print with 15.8 MP?

The maximum print size of the Panasonic GX800 for good quality output (200 dots per inch) amounts to 23 x 17.2 inches or 58.3 x 43.8 cm, for very good quality (250 dpi) 18.4 x 13.8 inches or 46.7 x 35 cm, and for excellent quality (300 dpi) 15.3 x 11.5 inches or 38.9 x 29.2 cm. Few people actually print their images that large on a regular basis, but it is nice to have the option to make very large prints of exceptional shots. Also, as mentioned earlier, a key advantage of high-MP cameras is that it is possible to crop an image ex-post and thereby, for example, change the composition of the capture or zoom in on some detail.

ad

Sensor specs and performance

The table below compares the sensor specs of the Panasonic GX800 to those of several similar cameras. In addition to sensor class and megapixel count, DXO values are reported as indicators of the sensor's imaging quality (higher is better). Three aspects are covered: color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.

scroll hint
Sensor Characteristics
    Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
1.

Panasonic GX800 Four Thirds 15.8 4592 34484K/30p23.213.358673
2.

Canon M10 APS-C 17.9 5184 34561080/30p22.211.475365
3.

Canon M100 APS-C 24.0 6000 40001080/60p23.512.9127278
4.

Panasonic G5 Four Thirds 15.9 4608 34561080/60p21.411.661861
5.

Panasonic G6 Four Thirds 15.9 4608 34561080/60p21.311.563961
6.

Panasonic G7 Four Thirds 15.8 4592 34484K/30p22.812.490471
7.

Panasonic GF5 Four Thirds 12.0 4000 30001080/60i20.510.057350
8.

Panasonic GF6 Four Thirds 15.8 4592 34481080/60i20.710.662254
9.

Panasonic GF7 Four Thirds 15.8 4592 34481080/60p22.712.387470
10.

Panasonic GM1 Four Thirds 15.8 4592 34481080/60i22.311.766066
11.

Panasonic GM5 Four Thirds 15.8 4592 34481080/60p22.111.772166
Note: DXO values in italics represent estimates based on sensor size and age.
Further information on the sensor in the Panasonic GX800 and the camera's operation can be found in the camera manual.

In the United States, the GX800 was initially launched in January 2017 at a price of $549.

logo
Check GX800 offers at
ebay.com

Camera to camera comparisons

In case you would like to check on the differences and similarities with other camera models, just make a corresponding selection in the search boxes below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.

~
    loader
    ad

    Specifications Summary
    Camera Model Panasonic GX800
    Camera Type Mirrorless system camera
    Camera Lens Micro Four Thirds lenses
    Launch Date January 2017
    Launch Price USD 549
    Sensor Specs
    Sensor Technology CMOS
    Sensor Format Four Thirds Sensor
    Sensor Size 17.3 x 13.0 mm
    Sensor Area 225 mm2
    Sensor Diagonal 21.6 mm
    Crop Factor 2.0x
    Sensor Resolution 15.8 Megapixels
    Image Resolution 4 592 x 3 448 pixels
    Pixel Pitch 3.77 μm
    Pixel Density 7.04 MP/cm2
    Moiré control no AA filter
    Movie Capability 4K/30p Video
    ISO Setting 200 - 25 600 ISO
    ISO Boost 100 - 25 600 ISO
    Image Processor Venus
    DXO Sensor Quality (score) 73
    DXO Color Depth (bits) 23.2
    DXO Dynamic Range (EV) 13.3
    DXO Low Light (ISO) 586
    Screen Specs
    Viewfinder Type No viewfinder
    Top-Level Screen no Top Display
    LCD Framing Live View
    LCD Size 3.0 inch
    LCD Resolution 1040k dots
    LCD Attachment Tilting screen
    V-logging Friendliness Front-flip possible
    Touch Input Touchscreen
    Shooting Specs
    Focus System Contrast-detect AF
    Manual Focusing AidFocus Peaking
    Maximum Shutter Speed 1/500s
    Continuous Shooting 10 shutter flaps/s
    Shutter Life Expectancy100 000 actuations
    Silent ShootingElectronic Shutter
    Time Lapse PhotographyIntervalometer Built-in
    Fill Flash Built-in Flash
    Storage Medium SDXC cards
    Single or Dual Card Slots Single card slot
    UHS card support UHS-I
    Connectivity Specs
    External Flash no Hotshoe
    USB Connector USB 2.0
    HDMI Port micro HDMI
    Wifi Support Wifi built-in
    Body Specs
    Battery Type Panasonic DMW-BLH7 power pack
    Battery Life (CIPA)210 shots per charge
    Body Dimensions 107 x 65 x 33 mm
    (4.2 x 2.6 x 1.3 in)
    Camera Weight 269 g (9.5 oz)

    Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
