LCD resolution of the Panasonic GX7
The rear LCD screen of the Panasonic Lumix DMC-GX7 has a resolution of 1,040,000 dots and measures 3.0 inches across its diagonal. A high-resolution display offers a clearer and crisper user experience than a lower pixel screen, notably during live view framing and image review. While the physical size of the LCD is naturally limited by the space that is available on the back of the camera, the resolution of the rear screen has continued to increase over time, with new camera models often featuring nicer rear panels as one of the key arguments for a camera upgrade.
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.70x | |
Viewfinder Resolution | 2760k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1040k dots | |
LCD Attachment | Tilting screen | |
Touch Input | Touchscreen |
In terms of screen handling characteristics, the LCD of the Panasonic GX7 is touch sensitive and is flexibly attached to the body to allow for odd-angle shots.
Back side of the Panasonic GX7 with LCD
As can be seen from the rear-side image, the 3.0-inch LCD occupies a large part of the backside of the camera. For comparison, the diagonal on a standard credit card measures 4 inches.
Camera to camera comparisons
The Panasonic Lumix DMC-GX7 is a mirrorless interchangeable lens camera that was announced in August 2013 and is equipped with a Four Thirds sensor. It offers a resolution of 15.8 megapixel. In the United States, the Panasonic GX7 was initially launched at a price of $999.
The table below compares the rear screen specs of the Panasonic GX7 to those of several similar cameras. Additionally, the table includes some information on other core features, such as the viewfinder, shutter, flash, and image stabilization system.
Camera Model |
Viewfinder (Type or 000 dots) |
Control Panel (yes/no) |
LCD Specifications (inch/000 dots) |
LCD Attach- ment |
Touch Screen (yes/no) |
Mech Shutter Speed |
Shutter Flaps (1/sec) |
Built-in Flash (yes/no) |
Built-in Image Stab |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Panasonic GX7 | 2760 | n | 3.0 / 1040 | tilting | Y | 1/8000s | 5.0/s | Y | Y | |
2. | Olympus E-M10 | 1440 | n | 3.0 / 1037 | tilting | Y | 1/4000s | 8.0/s | Y | Y | |
3. | Olympus E-P5 | optional | n | 3.0 / 1037 | tilting | Y | 1/8000s | 9.0/s | Y | Y | |
4. | Olympus E-PL7 | optional | n | 3.0 / 1037 | tilting | Y | 1/4000s | 8.0/s | n | Y | |
5. | Panasonic G5 | 1440 | n | 3.0 / 920 | swivel | Y | 1/4000s | 6.0/s | Y | n | |
6. | Panasonic G6 | 1440 | n | 3.0 / 1036 | swivel | Y | 1/4000s | 7.0/s | Y | n | |
7. | Panasonic G85 | 2360 | n | 3.0 / 1040 | swivel | Y | 1/4000s | 9.0/s | Y | Y | |
8. | Panasonic GH2 | 1534 | n | 3.0 / 460 | swivel | n | 1/4000s | 3.0/s | Y | n | |
9. | Panasonic GM5 | 1166 | n | 3.0 / 921 | fixed | Y | 1/500s | 5.8/s | n | n | |
10. | Panasonic GX8 | 2360 | n | 3.0 / 1040 | swivel | Y | 1/8000s | 10.0/s | n | Y | |
11. | Panasonic GX85 | 2765 | n | 3.0 / 1040 | tilting | Y | 1/4000s | 8.0/s | Y | Y | |
Note: *) Information refers to the mechanical shutter, unless the camera only has an electronic one. |
One convenient feature of the GX7 is the presence of an on-board flash. While this built-in flash is not very powerful, it can at times be useful as a fill-in light to brighten deep shadow areas.
If you would like to see a side-by-side review with another camera, just make a corresponding selection in the search boxes below. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.
- Canon 100D vs Panasonic GX7
- Canon 1D Mark III vs Panasonic GX7
- Canon SX520 vs Panasonic GX7
- Fujifilm X30 vs Panasonic GX7
- Nikon 1 J5 vs Panasonic GX7
- Nikon D1X vs Panasonic GX7
- Panasonic GF3 vs Panasonic GX7
- Panasonic GH4 vs Panasonic GX7
- Panasonic GX7 vs Panasonic LX100 II
- Panasonic GX7 vs Pentax K-3
- Panasonic GX7 vs Sony H400
- Panasonic GX7 vs Sony HX99
Camera Model | Panasonic GX7 | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Micro Four Thirds lenses | |
Launch Date | August 2013 | |
Launch Price | USD 999 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | Four Thirds Sensor | |
Sensor Size | 17.3 x 13.0 mm | |
Sensor Area | 225 mm2 | |
Sensor Diagonal | 21.6 mm | |
Crop Factor | 2.0x | |
Sensor Resolution | 15.8 Megapixels | |
Image Resolution | 4 592 x 3 448 pixels | |
Pixel Pitch | 3.77 μm | |
Pixel Density | 7.04 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 1080/60p Video | |
ISO Setting | 125 - 25 600 ISO | |
Image Processor | Venus | |
DXO Sensor Quality (score) | 70 | |
DXO Color Depth (bits) | 22.6 | |
DXO Dynamic Range (EV) | 12.2 | |
DXO Low Light (ISO) | 718 | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.70x | |
Viewfinder Resolution | 2760k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1040k dots | |
LCD Attachment | Tilting screen | |
V-logging Friendliness | No front-flip | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/8000s | |
Continuous Shooting | 5 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | Electronic Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Image Stabilization | In-body stabilization | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | mini HDMI | |
Wifi Support | Wifi built-in | |
Near-Field Communication | NFC built-in | |
Body Specs | ||
Battery Type | Panasonic DMW-BLG10 power pack | |
Battery Life (CIPA) | 350 shots per charge | |
Body Dimensions |
123 x 71 x 55 mm (4.8 x 2.8 x 2.2 in) |
|
Camera Weight | 402 g (14.2 oz) |
